DEEPACE UHF Direction Finding Antenna R400 200MHz-500MHz

Description R400 is a lightweight/low-cost/easy-to-use VHF direction finding antenna that operates in the 200MHz-500MHz frequency range, easily supporting key frequency bands such as FM broadcast, UHF communication and direction finding, making it a great tool for RF field analysis. Provides complete support for UHF direction finding common frequency bands. It has good directivity within the working range, with a typical front-to-back ratio of 10dB, and a small secondary flap with clear directivity, making it suitable for direction finding operations with the KC908 handheld receiver.R200 adopts a weight-saving design, using aluminum and carbon fiber materials, which is lightweight and reduces the burden of direction finding operators. The passive antenna design is suitable for direction finding in strong signal scenarios. Product Highlights Accurate radiation pointing Determine the direction by pointing to the point of maximum amplitude of the received signal High bandwidth, good consistency Composite material design, ultra-light weight Passive antenna, not easy to be blocked Product Parameters Frequency range: 200MHz-500MHz Polarization: line polarization (vertical) Input impedance: 50Ω Voltage Standing Wave Ratio (VSWR): ＜2.5 Return Loss: 10dB typ Anterior-to-Posterior Ratio (APR): 10dB typ Size: 230 × 210mm including handle Weight: 150g Connector: sma
